Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 7020 | MH-7020QWC-0.5W | White | 2.8 | 3.4 | 60 | 80 | 6000 | 10000 | 150 | 120 |
| 7020 | MH-7020QWC-1W | White | 5.8 | 6.4 | 100 | 150 | 6000 | 10000 | 150 | 120 |
