Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity（mcd/LM/WM） | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Max | Min | Max | Min | Max | ||||||
| 5050 | MH-5050QRQPQGQYC | Red | 1.8 | 2.4 | 600 | 800 | 620 | 630 | 20*4 | 120 |
| Purple | 3.2 | 3.4 | 10 | 15 | 410 | 415 | ||||
| Green | 2.8 | 3.4 | 1500 | 2000 | 520 | 530 | ||||
| Yellow | 1.8 | 2.4 | 600 | 800 | 590 | 595 | ||||
| 5050 | MH-5050QRQGQBQWC | Red | 1.8 | 2.4 | 600 | 800 | 620 | 630 | 20*4 | 120 |
| Green | 2.8 | 3.4 | 1800 | 2100 | 520 | 530 | ||||
| Blue | 2.8 | 3.4 | 400 | 600 | 460 | 470 | ||||
| White | 2.8 | 3.4 | 7 | 8 | 4800 | 5200 | ||||
