Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity(mcd/LM) | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 3433 | MH-3433QRC | Red | 1.8 | 2.4 | 15 | 25 | 610 | 630 | 150 | 120 |
| 3433 | MH-3433QYC | Yellow | 1.8 | 2.4 | 15 | 20 | 580 | 600 | 150 | 120 |
| 3433 | MH-3433QFYC | Amber | 2.8 | 3.4 | 45 | 60 | 1500 | 2000 | 150 | 120 |
| 3433 | MH-3433QWC | White | 2.8 | 3.4 | 55 | 140 | 5000 | 8000 | 150/350 | 120 |
