Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 2mm | MH-2050QRQBC | Red | 1.8 | 2.4 | 300 | 500 | 620 | 630 | 20 | 30 |
| Blue | 2.8 | 3.4 | 800 | 1500 | 460 | 470 | 20 | 30 | ||
| 2mm | MH-2050QRQYGC | Red | 1.8 | 2.4 | 300 | 500 | 620 | 630 | 20 | 30 |
| Yellow- green | 1.8 | 2.4 | 50 | 100 | 565 | 575 | 20 | 30 | ||
| 2mm | MH-2050QRQGC | Red | 1.8 | 2.4 | 300 | 500 | 620 | 630 | 20 | 30 |
| Pure Green | 2.8 | 3.4 | 400 | 600 | 520 | 530 | 20 | 30 | ||
| 2mm | MH-2050QRQWC | Red | 1.8 | 2.4 | 300 | 500 | 620 | 630 | 20 | 30 |
| White | 2.8 | 3.4 | 2000 | 2500 | 7000 | 9000 | 20 | 30 | ||
| 2mm | MH-2050QRQNWC | Red | 1.8 | 2.4 | 300 | 500 | 620 | 630 | 20 | 30 |
| WarmWhite | 2.8 | 3.4 | 1500 | 2000 | 2700 | 3200 | 20 | 30 | ||
| 2mm | MH-2050QYQBC | Yellow | 1.8 | 2.4 | 200 | 400 | 585 | 595 | 20 | 30 |
| Blue | 2.8 | 3.4 | 200 | 400 | 460 | 470 | 20 | 30 | ||
