Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
5mm | MH-5084QRQOC | Red | 1.8 | 2.4 | 1200 | 2500 | 620 | 630 | 20 | 30 |
| Orange | 1.8 | 2.4 | 1200 | 2500 | 600 | 610 | 20 | 30 | ||
| 5mm | MH-5084QRQYC | Red | 1.8 | 2.4 | 1200 | 2500 | 620 | 630 | 20 | 30 |
| Yellow | 1.8 | 2.4 | 800 | 1200 | 585 | 595 | 20 | 30 | ||
| 5mm | MH-5084QRQBC | Red | 1.8 | 2.4 | 1200 | 2500 | 620 | 630 | 20 | 30 |
| Blue | 2.8 | 3.4 | 800 | 1500 | 460 | 470 | 20 | 30 | ||
| 5mm | MH-5084QRQYGC | Red | 1.8 | 2.4 | 1200 | 2500 | 620 | 630 | 20 | 30 |
| Yellow- green | 1.8 | 2.4 | 200 | 400 | 565 | 575 | 20 | 30 | ||
| 5mm | MH-5084QRQGC | Red | 1.8 | 2.4 | 1200 | 2500 | 620 | 630 | 20 | 30 |
| Pure Green | 2.8 | 3.4 | 3000 | 4000 | 520 | 530 | 20 | 30 | ||
| 5mm | MH-5084QYQGC | Yellow | 1.8 | 2.4 | 1000 | 1500 | 585 | 595 | 20 | 30 |
| Pure Green | 2.8 | 3.4 | 3000 | 4000 | 520 | 530 | 20 | 30 | ||
| 5mm | MH-5084QYQWC | Yellow | 1.8 | 2.4 | 1000 | 1500 | 585 | 595 | 20 | 30 |
| White | 2.8 | 3.4 | 3000 | 4000 | 10000 | 15000 | 20 | 30 | ||
| 5mm | MH-5084QGQWC | Pure Green | 2.8 | 3.4 | 5000 | 8000 | 520 | 530 | 20 | 30 |
| White | 2.8 | 3.4 | 9000 | 12000 | 10000 | 15000 | 20 | 30 | ||
| 5mm | MH-5084QBQGC | Blue | 2.8 | 3.4 | 1000 | 1500 | 460 | 470 | 20 | 30 |
| Pure Green | 2.8 | 3.4 | 3000 | 4000 | 520 | 530 | 20 | 30 | ||
