Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity(mcd/lm/MW) | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 2835 | MH-28QRC35 | Red | 1.8 | 2.4 | 2 | 20 | 620 | 630 | 20/60/150 | 120 |
| 2835 | MH-28QYC35 | Yellow | 1.8 | 2.4 | 2 | 15 | 585 | 595 | 20/60/150 | 120 |
| 2835 | MH-28QOC35 | Orange | 1.8 | 2.4 | 2 | 25 | 600 | 610 | 20/60/150 | 120 |
| 2835 | MH-28QBC35 | Blue | 2.8 | 3.4 | 1 | 20 | 460 | 470 | 20/60/150 | 120 |
| 2835 | MH-28QGC35 | Pure Green | 2.8 | 3.4 | 7 | 50 | 520 | 530 | 20/60/150 | 120 |
| 2835 | MH-28QPC35 | Purple | 3.0 | 3.4 | 6 | 8 | 390 | 400 | 20/60/150 | 120 |
| 2835 | MH-28WWC35 | Warm white | 2.8 | 3.4 | 12 | 80 | 2000 | 3000 | 20/60/150 | 120 |
| 2835 | MH-28NWC35 | Natural white | 2.8 | 3.4 | 12 | 80 | 5000 | 6500 | 20/60/150 | 120 |
| 2835 | MH-28CWC35 | Cool white | 2.8 | 3.4 | 12 | 60 | 8000 | 20000 | 20/60/150 | 120 |
