Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity(mcd/lm/MW) | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 2835 | MH-28QRC35-TJ | Red | 1.8 | 2.4 | 8 | 10 | 620 | 630 | 60 | 30/60 |
| 2835 | MH-28QYC35-TJ | Amber | 2.8 | 3.4 | 18 | 20 | 1600 | 1800 | 60 | 30/60 |
| 2835 | MH-28QWC35-TJ | White | 2.8 | 3.4 | 20 | 34 | 6000 | 6500 | 60 | 30/60 |
