Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 3025 | MH-3025QRQYC | Red | 1.8 | 2.4 | 440 | 850 | 620 | 630 | 20 | 60 |
| Yellow | 1.8 | 2.4 | 400 | 800 | 585 | 595 | 20 | |||
| 3025 | MH-3025QRQBC | Red | 1.8 | 2.4 | 440 | 850 | 620 | 630 | 20 | 60 |
| Blue | 2.8 | 3.4 | 300 | 800 | 460 | 470 | 20 | |||
| 3025 | MH-3025QRQGC | Red | 2.8 | 3.4 | 440 | 850 | 620 | 630 | 20 | 60 |
| Pure Green | 1.8 | 2.4 | 1600 | 2800 | 520 | 530 | 20 | |||
| 3025 | MH-3025QRQWC | Orange | 1.8 | 2.4 | 500 | 900 | 600 | 610 | 20 | 60 |
| Blue | 2.8 | 3.4 | 300 | 800 | 460 | 470 | 20 | |||
| 3025 | MH-3025QBQGC | Blue | 2.8 | 3.4 | 300 | 800 | 460 | 470 | 20 | 60 |
| Pure Green | 1.8 | 2.4 | 1600 | 2800 | 520 | 530 | 20 | |||
| 3025 | MH-3025QRQBQGC | Red | 2.8 | 3.4 | 440 | 850 | 620 | 630 | 20 | 60 |
Green | 1.8 | 2.4 | 1600 | 2800 | 520 | 530 | 20 | |||
| Blue | 2.8 | 3.4 | 300 | 800 | 460 | 470 | 20 | |||
