Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 3224 | MH-3224QRC | Red | 1.8 | 2.4 | 250 | 630 | 620 | 630 | 20 | 15 |
| 3224 | MH-3224QOC | Orange | 1.8 | 2.4 | 250 | 630 | 600 | 610 | 20 | 15 |
| 3224 | MH-3224QYC | Yellow | 1.8 | 2.4 | 250 | 630 | 585 | 595 | 20 | 15 |
| 3224 | MH-3224QYGC | Yellow-green | 1.8 | 2.4 | 100 | 250 | 560 | 570 | 20 | 15 |
| 3224 | MH-3224QGC | Pure Green | 2.8 | 3.4 | 1000 | 2500 | 520 | 530 | 20 | 15 |
| 3224 | MH-3224QBC | Blue | 2.8 | 3.4 | 250 | 630 | 465 | 475 | 20 | 15 |
| 3224 | MH-3224QWC | White | 2.8 | 3.4 | 1500 | 2000 | 2800 | 12000 | 20 | 15 |
