Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 1206 | MH-150QRC-DT | Red | 1.8 | 2.4 | 450 | 680 | 620 | 630 | 20 | 30 |
| 1206 | MH-150QYC-DT | Yellow | 1.8 | 2.4 | 180 | 230 | 585 | 595 | 20 | 30 |
| 1206 | MH-150QOC-DT | Orange | 1.8 | 2.4 | 280 | 450 | 600 | 610 | 20 | 30 |
| 1206 | MH-150QYG-DT | Yellow-green | 1.8 | 2.4 | 30 | 80 | 565 | 575 | 20 | 30 |
| 1206 | MH-150QGC-DT | Pure Green | 2.8 | 3.4 | 800 | 1200 | 520 | 530 | 20 | 30 |
| 1206 | MH-150QBC-DT | Blue | 2.8 | 3.4 | 230 | 350 | 460 | 470 | 20 | 30 |
| 1206 | MH-150NWC-DT | White | 2.8 | 3.4 | 700 | 1200 | 2800 | 12000 | 20 | 30 |
