Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 3015 | MH-3015QRC | Red | 1.8 | 2.4 | 250 | 630 | 620 | 630 | 20 | 30 |
| 3015 | MH-3015QOC | Orange | 1.8 | 2.4 | 160 | 400 | 600 | 610 | 20 | 30 |
| 3015 | MH-3015QYC | Yellow | 1.8 | 2.4 | 160 | 400 | 585 | 595 | 20 | 30 |
| 3015 | MH-3015QYGC | Yellow-green | 1.8 | 2.4 | 80 | 200 | 560 | 570 | 20 | 30 |
| 3015 | MH-3015QGC | Pure Green | 2.8 | 3.4 | 630 | 1600 | 520 | 530 | 20 | 30 |
| 3015 | MH-3015QBC | Blue | 2.8 | 3.4 | 125 | 320 | 465 | 475 | 20 | 30 |
| 3015 | MH-3015QWC | White | 2.8 | 3.4 | 600 | 1800 | 2800 | 12000 | 20 | 30 |
