Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | ||||
MH-4080QRQGQBC | Red | 1.8 | 2.4 | 300 | 500 | 620 | 630 | 20 | 60 |
| Blue | 2.8 | 3.4 | 200 | 400 | 460 | 470 | 20 | 60 | |
| Green | 2.8 | 3.4 | 800 | 1000 | 520 | 530 | 20 | 60 | |
