Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | ||||
| MH-8010QRC | Red | 1.8 | 2.4 | 25 | 35 | 620 | 630 | 150 | 30 |
| MH-8010QYC | Yellow | 1.8 | 2.4 | 8 | 12 | 585 | 595 | 150 | 30 |
| MH-8010QBC | Blue | 2.8 | 3.4 | 10 | 12 | 460 | 470 | 150 | 30 |
| MH-8010QGC | Green | 2.8 | 3.4 | 30 | 35 | 520 | 530 | 150 | 30 |
| MH-8010NWC | White | 2.8 | 3.4 | 40 | 45 | 6000 | 12000 | 150 | 30 |
| MH-8010CWC | Warm White | 2.8 | 3.4 | 40 | 45 | 2800 | 3200 | 150 | 30 |
