Customized service:we can produce the smd led according to the parameters and package size
Ultra bright
High-power
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity(LM) | Wavelengthe(nm)/CCT(K) | Power dissipation(W) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| High-power | MH-HPQRQGQ BC | Red | 1.8 | 2.4 | 60 | 80 | 620 | 630 | 1-3 | 120 |
| Green | 2.8 | 3.4 | 80 | 100 | 520 | 530 | ||||
| Blue | 2.8 | 3.4 | 30 | 40 | 465 | 475 | ||||
