Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | ||||
| MH-3084QRC | Red | 1.8 | 2.4 | 3000 | 5000 | 620 | 630 | 20 | 30 |
| MH-3084QYC | Yellow | 1.8 | 2.4 | 2000 | 3000 | 585 | 595 | 20 | 30 |
| MH-3084QOC | Orange | 1.8 | 2.4 | 2000 | 3000 | 600 | 610 | 20 | 30 |
| MH-3084QBC | Blue | 2.8 | 3.4 | 800 | 1200 | 460 | 470 | 20 | 30 |
| MH-3084QGC | Green | 2.8 | 3.4 | 4000 | 5000 | 520 | 530 | 20 | 30 |
| MH-3084QYG | Yellow-green | 1.8 | 2.4 | 30 | 60 | 565 | 575 | 20 | 30 |
| MH-3084QPC | Purple | 3.0 | 3.4 | 8 | 15 | 390 | 400 | 20 | 30 |
| MH-3084WWC | Warm white | 2.8 | 3.4 | 3000 | 4000 | 2000 | 3000 | 20 | 30 |
| MH-3084NWC | Natural white | 2.8 | 3.4 | 4000 | 6000 | 5000 | 6500 | 20 | 30 |
| MH-3084CWC | Cool white | 2.8 | 3.4 | 4000 | 6000 | 8000 | 20000 | 20 | 30 |
