Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 3528 | MH-110QRQYC | Red | 1.8 | 2.4 | 200 | 400 | 620 | 630 | 20 | 120 |
| Yellow | 1.8 | 2.4 | 200 | 400 | 585 | 595 | ||||
| 3528 | MH-110QRQYGC | Red | 1.8 | 2.4 | 600 | 800 | 620 | 630 | 20 | 120 |
| Yellow-green | 1.8 | 2.4 | 100 | 200 | 585 | 595 | ||||
| 3528 | MH-110QRQBC | Red | 1.8 | 2.4 | 400 | 600 | 620 | 630 | 20 | 120 |
| Blue | 2.8 | 3.4 | 200 | 400 | 460 | 470 | ||||
| 3528 | MH-110QRQGC | Red | 1.8 | 2.4 | 600 | 800 | 620 | 630 | 20 | 120 |
| Pure Green | 2.8 | 3.4 | 1500 | 2000 | 520 | 530 | ||||
| 3528 | MH-110QBQGC | Blue | 2.8 | 3.4 | 300 | 500 | 460 | 470 | 20 | 120 |
| Pure Green | 2.8 | 3.4 | 1400 | 1800 | 520 | 530 | ||||
| 3528 | MH-110QWQGC | White | 2.8 | 3.4 | 1400 | 1600 | 5000 | 6000 | 20 | 120 |
| Green | 2.8 | 3.4 | 1200 | 1400 | 520 | 530 | ||||
| 3528 | MH-110QWQBC | White | 2.8 | 3.4 | 1400 | 1600 | 5000 | 6000 | 20 | 120 |
| Blue | 2.8 | 3.4 | 200 | 400 | 565 | 575 | ||||
| 3528 | MH-110QRQGQBC | Red | 1.8 | 2.4 | 200 | 400 | 620 | 630 | 20 | 120 |
| Pure Green | 2.8 | 3.4 | 1400 | 1800 | 520 | 530 | ||||
| Blue | 2.8 | 3.4 | 300 | 500 | 460 | 470 | ||||
| 3528 | MH-110QRQGQBC | Red | 1.8 | 2.4 | 600 | 800 | 620 | 630 | 20 | 120 |
| Pure Green | 2.8 | 3.4 | 1500 | 2000 | 520 | 530 | ||||
| White | 2.8 | 3.4 | 1600 | 2000 | 6000 | 7000 | ||||
