Customized service:we can produce the smd led according to the parameters and package size
1.5W power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous flux（LM） | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 3030 | MH-3030QRQGQBC-1.5W | Red | 1.8 | 2.4 | 15 | 30 | 615 | 635 | 150 | 120° |
| Green | 2.8 | 3.4 | 30 | 50 | 515 | 630 | ||||
Blue | 2.8 | 3.4 | 10 | 20 | 450 | 470 | ||||
| 3030 | MH-3030QRQGQBC-3W | Red | 1.8 | 2.4 | 35 | 45 | 615 | 635 | 300 | 120° |
| Green | 2.8 | 3.4 | 60 | 75 | 515 | 630 | ||||
| Blue | 2.8 | 3.4 | 25 | 35 | 450 | 470 | ||||
