Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
1.5-6W power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous flux（LM） | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 3535 | MH-3535TJQ AQWC-6W | Amber | 2.8 | 3.4 | 180 | 220 | 1500 | 2000 | 1000 | 120/90 |
| White | 2.8 | 3.4 | 280 | 320 | 5000 | 8000 | ||||
| 3535 | MH-3535TJQRQGQBC-3W | Red | 1.8 | 2.4 | 40 | 60 | 615 | 635 | 350 | 120/90/60 |
| Green | 2.8 | 3.4 | 60 | 80 | 515 | 530 | ||||
| Blue | 2.8 | 3.4 | 20 | 30 | 450 | 470 | ||||
| 3535 | MH-3535TJQRQGQBQWC-4W | Red | 1.8 | 2.4 | 40 | 60 | 615 | 635 | 350 | 120/90 |
| Green | 2.8 | 3.4 | 60 | 80 | 515 | 530 | ||||
| Blue | 2.8 | 3.4 | 20 | 30 | 450 | 470 | ||||
| White | 2.8 | 3.4 | 100 | 160 | 2800 | 8000 | ||||
| 3535 | MH-3535TJQRQGQPQYC-1.5W | Red | 1.8 | 2.4 | 15 | 20 | 615 | 635 | 150 | 120/90 |
| Green | 2.8 | 3.4 | 30 | 40 | 515 | 530 | ||||
| Purple | 2.8 | 3.4 | 2 | 3 | 410 | 415 | ||||
| Yellow | 1.8 | 2.4 | 15 | 20 | 585 | 595 | ||||
