Customized service:we can produce the smd led according to the parameters and package size
Ultra bright
High-power
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity(LM) | Wavelengthe(nm)/CCT(K) | Power dissipation(W) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 2016 | MH-2016QWC-1W | White | 2.8 | 3.4 | 120 | 150 | 2800 | 8000 | 1 | 120 |
| 2016 | MH-2016QWC-3W | White | 2.8 | 3.4 | 350 | 400 | 2800 | 8000 | 3 | 120 |
| 2016 | MH-2016QWC-5W | White | 2.8 | 3.4 | 500 | 600 | 2800 | 8000 | 5 | 120 |
