Customized service:we can produce the smd led according to the parameters and package size
Ultra bright
High-power
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity(LM) | Wavelengthe(nm)/CCT(K) | Power dissipation(W) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 1860 | MH-1860QYWC-15W | Yellow | 9 | 10 | 1000 | 1200 | 1500 | 2000 | 15 | 120 |
| 1860 | MH-1860QWC-15W | White | 9 | 10 | 1200 | 1500 | 5000 | 7000 | 15 | 120 |
| 1860 | MH-1860QWC-10W | White | 8.7 | 9.3 | 600 | 800 | 5000 | 7000 | 10 | 120 |
| 1860 | MH-1860QWC-6W | White | 8.8 | 9.3 | 800 | 1000 | 5000 | 7000 | 6 | 120 |
