Customized service:we can produce the smd led according to the parameters and package size
Ultra bright
High-power
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity(LM) | Wavelengthe(nm)/CCT(K) | Power dissipation(W) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 3570 | MH-3570QWQWMC-10W | White | 9 | 10 | 1100 | 1400 | 5000 | 10000 | 10 | 120 |
| Warm White | 9 | 10 | 1000 | 1300 | 1500 | 4000 | ||||
| 3570 | MH-3570QWC-18W | White | 9 | 10 | 2000 | 2300 | 5000 | 10000 | 18 | 120 |
| 3570 | MH-3570QWC-30W | White | 9 | 10 | 3000 | 3300 | 5000 | 10000 | 30 | 120 |
