Customized service:we can produce the smd led according to the parameters and package size
Ultra bright
High-power
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity(LM) | Wavelengthe(nm)/CCT(K) | Power dissipation(W) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 4575 | MH-4575QWC-30W | White | 9 | 10 | 1800 | 2200 | 2800 | 10000 | 30 | 120 |
| 4575 | MH-4575QYWC-50W | Yellow | 9 | 10 | 1500 | 3300 | 1500 | 2000 | 50 | 120 |
