Customized service:we can produce the smd led according to the parameters and package size
Suitable for all SMT assembly and solder process
Available on tape and reel
Low power consumption
I.C.Compatible
Long life solid state reliability
Low operating voltage
RoHS compliant
Electro optical characteristics(Ta=25°C)
| Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | ||||
| MH-9521PT-850-TR7 | PT | 1.2 | 1.5 | 5 | 15 | 840 | 860 | 20 | 35 |
| MH-9521PT-940-TR7 | PT | 1.2 | 1.5 | 5 | 15 | 930 | 960 | 20 | 35 |
| MH-9521IR-850-TR7 | IR | 1.2 | 1.5 | 5 | 15 | 840 | 860 | 20 | 35 |
| MH-9521IR-940-TR7 | IR | 1.2 | 1.5 | 5 | 15 | 930 | 960 | 20 | 35 |
