Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
1.5-6W power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 4014 | MH-4014QRC | Red | 1.8 | 2.4 | 6 | 8 | 620 | 630 | 60 | 120 |
| 4014 | MH-4014QYC | Yellow | 1.8 | 2.4 | 5 | 7 | 585 | 595 | 60 | 120 |
| 4014 | MH-4014QOC | Orange | 1.8 | 2.4 | 5 | 7 | 600 | 610 | 60 | 120 |
| 4014 | MH-4014QBC | Blue | 2.8 | 3.4 | 4 | 6 | 460 | 470 | 60 | 120 |
| 4014 | MH-4014QGC | Pure Green | 2.8 | 3.4 | 15 | 20 | 520 | 530 | 60 | 120 |
| 4014 | MH-4014WWC | Warm white | 2.8 | 3.4 | 20 | 22 | 2000 | 3000 | 60 | 120 |
| 4014 | MH-4014NWC | Natural white | 2.8 | 3.4 | 26 | 28 | 5000 | 6500 | 60 | 120 |
| 4014 | MH-4014CWC | Cool white | 2.8 | 3.4 | 20 | 22 | 8000 | 20000 | 60 | 120 |
