Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity(mcd/LM/MW) | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 3020 | MH-3020QRC | Red | 1.8 | 2.4 | 1 | 8 | 620 | 630 | 20/60 | 120 |
| 3020 | MH-3020QYC | Yellow | 1.8 | 2.4 | 1 | 7 | 585 | 595 | 20/60 | 120 |
| 3020 | MH-3020QOC | Orange | 1.8 | 2.4 | 1 | 8 | 600 | 610 | 20/60 | 120 |
| 3020 | MH-3020QBC | Blue | 2.8 | 3.4 | 1 | 6 | 460 | 470 | 20/60 | 120 |
| 3020 | MH-3020QGC | Pure Green | 2.8 | 3.4 | 2 | 20 | 520 | 530 | 20/60 | 120 |
3020 | MH-3020QPC | Purple | 3.3 | 3.6 | 40 | 60 | 365 | 370 | 60/150 | 120 |
| 3020 | MH-3020QIBC | Ice Blue | 2.8 | 3.4 | 6 | 7 | 100000 | 1000000 | 20 | 120 |
| 3020 | MH-3020WWC | White | 2.8 | 3.4 | 6 | 24 | 2800 | 40000 | 20/60 | 120 |
