Customized service:we can produce the smd led according to the parameters and package size
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity（LM） | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Max | Min | Max | Min | Max | ||||||
| 5050 | MH-5050RGBWWC | Red | 1.8 | 2.4 | 15 | 20 | 615 | 635 | 150 | 120 |
| Green | 2.8 | 3.4 | 35 | 45 | 515 | 530 | ||||
| Blue | 2.8 | 3.4 | 10 | 20 | 450 | 470 | ||||
| White | 2.8 | 3.4 | 50 | 80 | 5000 | 8000 | ||||
Warm White | 2.8 | 3.4 | 50 | 80 | 2500 | 3500 | ||||
