Customized service:we can produce the smd led according to the parameters and package size
Ultra bright
High-power
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Type | Part No | Emitted color | Forward voltage(Vf) | Luminous intensity(LM) | Wavelengthe(nm)/CCT(K) | Power dissipation(W) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | |||||
| 7070 | MH-7070QWC-20W | White | 6.0 | 6.6 | 2000 | 2500 | 6000 | 7000 | 20 | 120 |
| 7070 | MH-7070QYWC-60W | White | 9.0 | 9.6 | 4500 | 5000 | 6000 | 7000 | 60 | 120 |
