Customized service:we can produce the smd led according to the parameters and package size
Small apprearance
Low power consumption
Wide view angle
Long life
High reliablity
Energy-saving
High brightness
RoHS Compliant
Electro optical characteristics(Ta=25°C)
| Part No | Emitted color | Forward voltage(Vf) | Luminous intensity | Wavelengthe(nm)/CCT(K) | Current(Ma) | Viewing angle | |||
| Min | Max | Min | Max | Min | Max | ||||
| MH-150PT-850 | PT | 1.2 | 1.5 | 5 | 15 | 840 | 860 | 20 | 120 |
| MH-150PT-940 | PT | 1.2 | 1.5 | 5 | 15 | 930 | 960 | 20 | 120 |
| MH-150IR-850 | IR | 1.2 | 1.5 | 5 | 15 | 840 | 860 | 20 | 120 |
| MH-150IR-940 | IR | 1.2 | 1.5 | 5 | 15 | 930 | 960 | 20 | 120 |
